SWOOD CAM

SWOOD CAM

Machining and producing woodworking inside SOLIDWORKS.

SWOOD CAM manages NC machines dedicated to woodworking and their technologies. Features include woodworking specific operations such as sawing, mortising, tenoing and grooving.

In stock

Capabilities

Integration into SOLIDWORKS

• Manufacturing treeview in Feature Manager

• Tools, Agregates and machining macros library in Task Pane

• Insert library items by drag & drop

• Machining simulation in the SOLIDWORKS view including machine environment

• Panel an worktable devices positioning in the SOLIDWORKS view



Technology

• Multiple spindles, multiple drilling aggregate and horizontal spindle

• Multiple Head

• Chip suction and deflector management

• Automatic modulation of feed speed according to grain direction

• Blocked on flat table or with consoles and suction cups

• Laser projection

• Multiple positioning

• Parametric worktable management

• Woodworking cycle: grooving, sawing, mortising, tenoning

• Nesting as an option



Encoding

Numerous NC machines already managed thanks to a customisable machine code

• HOMAG

• SCM

• BIESSE

• IMA

• MASTERWOOD

Time file export



Reporting

• Customized production documents generation

• Cut list

• Programs list

• Tools list

• Labels (with barcode)

• Batch encoding and full project export
